Morbidelli Author 213 - Centro de Mecanizado CNC
Especificaciones
| Fabricante | Morbidelli |
| Modelo | Author 213 |
| Condición | Usado |
| Fabricado en | Italia |
| Rango de fresado | 2748 x 865 mm |
| Rango de perforación | 2812 x 812 mm |
| Rango con todas las herramientas | 2670 x 649 mm |
| Grosor del panel | 55 mm |
| Desplazamiento vertical de herramienta neumática | 60 mm |
| Velocidad del eje vectorial | 75 m/min |
| Potencia del motor de fresado | 4 HP |
| Velocidad del husillo | 16000 rpm |
| Velocidad de la unidad de corte | 6000 rpm |
| Voltaje | 380 V trifásico |
| Dimensiones | L 3780 x W 2175 x H 1655 mm |
| Peso | 2000 kg |
| Disponibilidad | Inmediata |
| Observaciones | *¡La información puede ser a veces inexacta y cambiar sin previo aviso! |
Descripción
Woodworking - CNC Machining Center
Used Morbidelli industrial machinery – Author 213 located in Belgium. This CNC machining center has a milling range of 2748 x 865 mm, 16000 rpm spindle speed and power milling motor of 4 HP.
More info:
Machine with one drilling unit with 9 independent vertical drilling heads (distance 32 mm), 5 drilling heads in line on axis X, 6 drilling heads in line on axis Y, 1 independent double head for horizontal drilling in X axis, motor drilling unit 4 hp, independent pneumatic position of all drill heads (course 60 mm), 6 transverse tables with 2 vacuum tensioners per table for workpiece positioning, two interchangeable machining zones, double reference datum for right and left machining with 6 rear stops and 2 lateral stops, vacuum pump 40 mc/h, ball nut drive, dust extraction hoods, continuous control over 3 axes, Linear, circular and helicoidal interpolation and CE protection.
For more information please download the brochure.
____
* Please note that this description may have been translated automatically. The information of this classified ad are only indicative and change without notice! GLOMACHT recommends to check the details with the seller. Contact us for further information.*
