Stama MC 010 - Centro de Mecanizado Vertical - 1990
Especificaciones
| Fabricante | Stama |
| Modelo | MC 010 |
| Año | 1990 |
| Condición | Usado |
| Unidad de control | Fanuc O - M |
| Recorrido del eje X | 500 mm |
| Recorrido del eje Y | 380 mm |
| Recorrido del eje Z | 330 mm |
| Longitud de la mesa | 650 mm |
| Ancho de la mesa | 380 mm |
| Carga de la mesa | 200 kg |
| Cono del husillo | SK 30 |
| Velocidad del husillo | 6000 rpm |
| Potencia del motor | 5.5 kW |
| Revistero | 10 lugares |
| Dimensiones | L 2000 x W 1600 x H 2500 mm |
| Peso | 2200 kg |
| Disponibilidad | Inmediata |
| Observaciones | *¡La información puede ser a veces inexacta y cambiar sin previo aviso! |
Descripción
Metalworking - Vertical Machining Centre
Used Stama industrial machinery – MC 010 from 1990 located in France. This vertical machining centre is equipped with a control unit Fanuc O - M and has a working area of 650 x 380 mm, 6000 rpm spindle speed and motor power 5.5 kW.
More info:
Machine with 3 axis includes a set of tool holders supplied with the machine (at least 20 ER collet holders), spindle rebuilt (bearings and spindle nose cone rectification) less than 200h ago, new keyboard diaphragms.
Sold without the vice and with 50 tool holders.
____
* Please note that this description may have been translated automatically. The information of this classified ad are only indicative and change without notice! GLOMACHT recommends to check the details with the seller. Contact us for further information.*
