Torno CNC Pinacho ST 500 - 4000 - 2015
Vendido
Especificaciones
| Fabricante | Pinacho |
| Modelo | ST 500 - 4000 |
| Año | 2015 |
| Condición | Usado |
| Fabricado en | España |
| Unidad de control | Fanuc Oi TD |
| Máx. diámetro sobre el banco | 1000 mm |
| Máx. longitud de la pieza de trabajo | 4000 mm |
| Recorrido del carro transversal | 500 mm |
| Máx. diámetro sobre el carro transversal | 718 mm |
| Ancho de la cama | 500 mm |
| Diámetro del husillo | 130 mm |
| Morsa | 120 mm |
| Recorrido del husillo de la morsa | 300 mm |
| Velocidad del husillo | 1400 rpm |
| Avance rápido x / z | 10 m / min |
| Potencia del motor | 22 Kw |
| Dimensiones | L 7325 x W 1800 x H 2230 mm |
| Peso | 7600 Kg |
| Disponibilidad | Inmediata |
| Observaciones | *¡La información puede ser a veces inexacta y cambiar sin previo aviso! |
Descripción
Metalworking - CNC Lathe
Used Pinacho – ST 500 - 4000 from 2015 made in Spain located in Spain. This CNC lathe is equipped with a control unit Fanuc Oi TD and has a working area of 4000 x 1000 mm, 1400 rpm spindle speed, power motor 22 kW.
Includes the following:
- Automatic turret Hydraulic V8
- C axis + Brake
- Pressing
- Hydraulic chuck
- Window
- Chip extractor
- Smoke extractor – not included
____
* Please note that this description may have been translated automatically. The information of this classified ad are only indicative and change without notice! GLOMACHT recommends to check the details with the seller. Contact us for further information.*
